ADG508FBN Dual Supply Interface-IC Switches Electronic Components
ADG508FBN Dual Supply Interface-IC Switches Electronic Components
ADG508FBN Dual Supply Interface-IC Switches Electronic Components

ADG508FBN Dual Supply Interface-IC Switches Electronic Components

Model NO.
ADG508FBN
Price:
USD 0.10-10.00 / pieces
Minimum order quantity:
10 pieces
Supply Ability:
180000 pieces / Day
Country of Origin:
Shen Zhen
Quantity:
  • Place of Origin:US;1003
  • Type:LOGIC ICS
  • Brand Name:Brand
  • Model Number:ADG508FBN
  • Package / Case:16-DIP (0.300", 7.62mm)
  • Operating Temperature:-40°C ~ 85°C
  • Dissipation Power:W
  • Application:Computer
  • Supply Voltage:±15V



DatasheetsADG508F,509F
Product PhotosDIP16_SOT38-1 PKG
Product Training ModulesiCMOS™ Switches and Multiplexers for Data Acquisition
Switch Fundamentals
Standard Package25
CategoryIntegrated Circuits (ICs)
FamilyInterface - Analog Switches, Multiplexers, Demultiplexers
Series-
FunctionMultiplexer
Circuit1 x 8:1
On-State Resistance270 Ohm
Voltage Supply SourceDual Supply
Voltage - Supply, Single/Dual (±)±15V
Current - Supply100nA
Operating Temperature-40°C ~ 85°C
Mounting TypeThrough Hole
Package / Case16-DIP (0.300", 7.62mm)
Supplier Device Package16-PDIP
PackagingTube
Dynamic CatalogMultiplexer/Demultiplexer



Real Pictures Show :
