IRFZ34N N-Channel Power MOSFET NPN Transistor
IRFZ34N N-Channel Power MOSFET NPN Transistor

IRFZ34N N-Channel Power MOSFET NPN Transistor

Model NO.
IRFZ34N
Price:
USD 0.10-10.00 / pieces
Minimum order quantity:
100 pieces
Supply Ability:
500000 pieces / Day
Country of Origin:
Shenzhen
Quantity:
  • Place of Origin:US;1003
  • Model Number:IRFZ34N
  • Brand Name:brand
  • Type:Bipolar Junction Transistor
  • Package Type:TO-220-3
  • Family:Transistors (BJT) - Single
  • Transistor Type:NPN
  • Quality:100% New and original
  • Stock:In stock



DatasheetsIRFZ34NPbF
Product PhotosTO-220AB PKG
Product Training ModulesHigh Voltage Integrated Circuits (HVIC Gate Drivers)
Design ResourcesIRFZ34NPBF Saber Model
IRFZ34NPBF Spice Model
PCN Assembly/OriginTO-220 FET Alternate Site 05/Dec/2013
Standard Package ? 50
CategoryDiscrete Semiconductor Products
FamilyFETs - Single
SeriesHEXFET®
Packaging ? Tube ?
FET TypeMOSFET N-Channel, Metal Oxide
FET FeatureStandard
Drain to Source Voltage (Vdss)55V
Current - Continuous Drain (Id) @ 25°C29A (Tc)
Rds On (Max) @ Id, Vgs40 mOhm @ 16A, 10V
Vgs(th) (Max) @ Id4V @ 250µA
Gate Charge (Qg) @ Vgs34nC @ 10V
Input Capacitance (Ciss) @ Vds700pF @ 25V
Power - Max68W
Mounting TypeThrough Hole
Package / CaseTO-220-3
Supplier Device PackageTO-220AB
Dynamic CatalogN-Channel Standard FETs
Other Names*IRFZ34NPBF
